Sharp LC-42D43U Service Manual

Also see for Aquos LC-42D~43U: Operation manual Operation manual Service manual Operation manual

Contents

OUTLINE AND MODIFIED PARTS LISTOUTLINE.............................................................iMODIFIED PARTS LIST .....................................iSAFETY PRECAUTIONIMPORTANT SERVICE SAFETY PRE-CAUTION ...........................................................iiPRECAUTIONS A PRENDRE LORS DELA REPARATION .............................................. iiiCHAPTER 1. OPERATION MANUAL[1] SPECIFICATIONS ......................................... 1-1[2] OPERATION MANUAL .................................. 1-2[3] DIMENSIONS ................................................ 1-8CHAPTER 2. REMOVING OF MAJOR PARTS[1] REMOVING OF MAJOR PARTS ................... 2-1CHAPTER 3. ADJUSTMENT[1] ADJUSTMENT PROCEDURE ......................3-1CHAPTER 4. TROUBLESHOOTING TABLE[1] TROUBLESHOOTING TABLE ......................4-1CHAPTER 3. OVERALL WIRING DIAGRAM/BLOCKDIAGRAM[1] OVERALL WIRING DIAGRAM......................3-1[2] SYSTEM BLOCK DIAGRAM.........................3-3CHAPTER 4. SCHEMATIC DIAGRAM[1] DESCRIPTION OF SCHEMATIC DIA-GRAM............................................................4-1[2] SCHEMATIC DIAGRAM ................................4-2Parts GuideSERVICE MANUALParts marked with " " are important for maintaining the safety of the set. Be sure to replace these parts with specified ones for maintaining thesafety and performance of the set.This document has been published to be used forafter sales service only.The contents are subject to change without notice.TopPageCONTENTSLC-42D43UNo.S07T9LC42D43ULCD COLOR TELEVISIONLC-42D43UMODELIn the interests of user-safety (Required by safety regulations in some countries) the set should be restored to its orig-inal condition and only parts identical to those specified should be used.In the interests of user-safety (Required by safety regulations in some countries) the set should be restored to its orig-inal condition and only parts identical to those specified should be used.For this model, the main unit is changed.When servicing the product, use this manual with the service manual LC-32/37D42U (S06X9LC32D42U) alreadyissued.The new model can be identified with the following markings.• The A character is added at the end of the model name on the model label.• The A character is also added at the end of the model name on the number label (barcode label) of thepacking case.• The serial product numbers (in the 1 th thru 9th digits) are 710802401 and on.OUTLINE
