Haier LET32H320 Service Manual

First, ensure that the remote control is set up correctly as described in section 6-3. If the issue persists, refer to the troubleshooting section 9 for further guidance.

The Haier LET32H320 supports a maximum resolution of 1920x1080.

The Haier LET32H320 requires a power input of AC150V~240V with a frequency of 50~60Hz.

To remove the stand from your Haier LET32H320 TV, follow these steps: 1. Lay down the TV set. 2. Remove the screw from the stand which is indicated with a circle in the picture. 3. Remove the stand.

To connect a DVD player to the Haier LET32H320 TV using the component inputs, connect the DVD video outputs (Y, Pb, Pr) to the COMPONENT (Y, Pb, Pr) IN socket on your TV. Turn on the DVD player and insert a DVD. Press the button to select the appropriate input mode and refer to the DVD player user guide for further operating instructions.

To reset your Haier LET32H320 TV to its default settings, you can use the 'RESET ALL' function. This will clean up the EEPROM data and restore the TV to its factory default mode.

To update the software on your Haier LET32H320 TV, plug a USB drive with the new software into the USB port. Then, select the opposite software and press the 'right button' to initiate the update process.

A horizontal gray line on the screen of the Haier LET32H320 can be caused by a TCP failure, panel failure, mis-alignment between TCP and LCD, or something electric entering the panel.

The backlight brightness may be darker than normal due to a damaged B/L wire or a short circuit between the lamp housing and the wire, which can cause excessive power consumption.

If the backlight shuts down intermittently, it could be due to a damaged B/L wire, a short circuit, or mechanical noise from the backlight unit. Check the connections and the wire for any signs of damage or badness.
