Haier LET19C430 User Manual

The box includes a remote control, AAA batteries (x2), an instruction manual, a quick start guide, a Scart cable (x1), and an adaptor.

The 19" model is an HD Ready LED LCD TV, while the 22" model is a Full HD 1080P Digital LED LCD TV. The 22" model offers a higher resolution.

Do not block the ventilation holes in the back cover. Adequate ventilation is essential to prevent failure of electrical components.

The Haier LET19C430 supports the following resolution settings: 640x480, 800x600, 1024x768, 1360x768, 1280x1024, and 1920x1080 (only for 21.5" and 23.6" models).

In TV mode, press the CH+ or CH- button on the remote control to change the channel up and down.

The indicator LED on the remote control sensor will be BLUE when the TV is powered on and RED when the TV is in standby mode.

If there is no signal for 15 minutes and the Auto Sleep feature is set to ON, the TV will automatically go into sleep mode. The clock time can be obtained from the DTV system automatically.

To prepare your USB device for recording, go to the OPTION MENU and select 'check PVR File System'. Click 'OK' and wait until the status changes to 'Success'. Ensure the 'speed' is set to 'HD support'. If not, format the device to make it compatible for recording.

If the space on your USB device is not sufficient, the record time will be shorter depending on the available space. The default 'Free Record Limit' is 6 hours, but this will adjust based on the available space on the device.

To record a currently watched digital program, insert a USB storage device into the USB port on the side of your TV while in the DTV input source. Press the PAUSE button to start the Time Shift function, which will pause the program and begin recording it to the USB device. To stop recording, press the STOP button.
