Haier LET19C430 User Manual

Also see for LET19C430: User manual

Language
GBEnglish
Contents
  1. Contents2
  2. Important Information3
  3. Safety and Warnings3
  4. Safety Notice4
  5. Warnings and Cautions5
  6. Installation6
  7. Main Features6
  8. Main Parameter6
  9. Preset Mode7
  10. Base Stand Assembly8
  11. Installation Notes8
  12. Wall Mounting Installation Guidelines9
  13. Remote Control10
  14. Front Control Panel10
  15. Rear/Side Sockets10
  16. Antenna Connection11
  17. Connect Your PC to the TV11
  18. Connecting Your TV11
  19. Scart Input11
  20. Common Interface12
  21. Insert Batteries into the Remote Control13
  22. Teletext14
  23. Auto Tuning15
  24. Channel Menu15
  25. Installation Guide15
  26. Operation15
  27. Sound Menu16
  28. CI Information16
  29. Program Edit16
  30. Picture Menu16
  31. EPG Menu17
  32. Lock Menu17
  33. Option Menu17
  34. Format18
  35. Prepare to Record the Program18
  36. PVR Function18
  37. Play the Record19
  38. Record the Program19
  39. USB Drive Storage Format20
  40. Timeshift Function20
  41. Record a Paused DTV Program to USB Storage Device20
  42. Time Shift Limitations21
  43. USB Player22
  44. Troubleshooting23
  45. Scart Input/Output Description24
  46. Specification24
  47. Table of Contents26
  48. 1 Sicherheits- und Warnhinweise27
  49. 2 Einleitung31
  50. 3 Fernbedienung39
  51. 4 Bedienungshinweise41
  52. 5 Störungserkennung55
Haier LET19C430 User Manual Manual pdf 22 page image
P.21Press source key, and selsct USB in sourelist, press OK button to enter the USB menu.10.USB PlayerPlease make sure that the USB device haveplugged in the slot.There are four type mediaitem can be selected, such as photo, music,Movie, and text. Select the type media item bypressing , press OK button to enterthe disk selection menu.PHOTO MUSIC MOVIE TEXTUSB 2.0Return C1/1Press the to select the right disk and pressOK to display media files and folder list orchoose Return to back to the media typeselection menu.Select the media file by pressing or , thenthe preview frame will pop up.Press the buttonto play the media file in full screen.When themedia file (photo,music, Movie, or text type) isplaying, press the OK or Info button can displaythe control bar.Press to select the function icon, press OKbutton to confirm the function.Press or EXIT button to exit the control bar.NOTE:You can adjust the audio track, or program in theInfo menu while Playing the video file.Choose theInfo icon and press OK can display the Info MENU.Pause FF Prev . Ne xtFB Stop Repeat ALL00:00:33/00:04:22Inf o.Sample1.tsResolution: 720x576Subtitle: 1/1Program: 1/6Size: 30574 KBytesCloseAudioTrack: 1/2Sample1.ts Sample2.tsReturnMovies1/1Sample3.ts Sample4.tsResolution: 688x412AudioTrack: 1/2Subtitle: 1/1Program: 1/5Size: 511457 KBytesSample1.ts
