Haier LE43K6500TF Service Manual

The Haier LE43K6500TF TV supports an aerial connection with IEC(female) and has an input impedance of 75 unbalanced.

To connect a DVD player or Set Top Box to the Haier LE43K6500TF TV using HDMI, follow these steps: 1. Connect the source device to the HDMI port of the TV using an HDMI cable (not supplied with the product). 2. No separate audio connection is necessary. To use, select the HDMI input source in the input source option of the Select Main source menu. If the source device supports Auto HDMI, the output resolution will be automatically set to 1280x720p. If not, adjust the output resolution of the source device to 1280x720p for the best picture quality.

To adjust the volume, use the 'V+' or 'V-' buttons on the front panel or the remote control. These buttons will increase or decrease the sound level, respectively.

The PWM_DIM and BL_ON signals are part of the electrical components diagram for the TV. PWM_DIM likely controls the dimming of the backlight, while BL_ON is related to the backlight power control. These signals are crucial for managing the display's brightness and power states.

To change the OSD language, follow these steps: 1. When the TV is turned on for the first time or reset to factory settings, the Initialization set-up menu will appear. 2. Use the ▲▼ buttons to navigate to your desired language. 3. Press the OK button to confirm your selection.

To move a channel, use the Arrow Buttons to select the channel you wish to move. Then press the Yellow Button to select the Move function. Once active, use the Arrow Buttons to move the channel to the desired position and then press OK to confirm.

To adjust the sound settings, go to the SOUND MENU, which is the third item in the MENU. Here, you can adjust various sound effects such as treble, bass, balance, and select different sound modes like Standard, Music, Theater, or User.

To record a program, first format the device by selecting 'High Speed FS' to speed up the recording process. While playing the DTV source, choose the channel you want to record. Click the '●record' button, and the record frame will pop up. Click 'record' again to start recording. The 'REC' icon will appear at the top left and will disappear once you click 'stop'.

If the video becomes pixelated, it may be due to a low video bit rate. This can happen if you are using a USB extension cable instead of plugging the USB directly into the TV. Ensure that the USB device is compatible and connected directly to the TV for the best results.

To play a video file from a USB device, press the source key and select USB in the source list. Then, press the OK button to enter the USB menu. Use the arrow keys to select the video file and press OK to start playback. You can also adjust the audio track or program in the Info menu while playing the video file.
