Haier LE22D10 Service Manual

Contents

Service ManualModel No.:- -e e o e o- . el0Pin No Symbol Function Remark1 RXO0- Negative Transmission data of Pixel 0 (ODD)2 RXO0+ Positive Transmission data of Pixel 0 (ODD)3 RXO1- Negative Transmission data of Pixel 1 (ODD)4 RXO1+ Positive Transmission data of Pixel 1 (ODD)5 RXO2- Negative Transmission data of Pixel 2 (ODD)6 RXO2+ Positive Transmission data of Pixel 2 (ODD)7 GND Power Ground8 RXOC- Negative Transmission Clock (ODD)9 RXOC+ Positive Transmission Clock (ODD)10 RXO3- Negative Transmission data of Pixel 3 (ODD)11 RXO3+ PositiveTransmission data of Pixel 3 (ODD)12 RXE0- Negative Transmission data of Pixel 0 (EVEN)13 RXE0+ Positive Transmission data of Pixel 0 (EVEN)14 GND Power Ground15 RXE1- Negative Transmission data of Pixel 1 (EVEN)16 RXE1+ Positive Transmission data of Pixel 1 (EVEN)17 GND Power Ground18 RXE2- Negative Transmission data of Pixel 2 (EVEN)19 RXE2+ Positive Transmission data of Pixel 2 (EVEN)20 RXEC- Negative Transmission Clock (EVEN)21 RXEC+ Positive Transmission Clock (EVEN)22 RXE3- Negative Transmission data of Pixel 3 (EVEN)23 RXE3+ Positive Transmission data of Pixel 3 (EVEN)24 GND Power Ground Note125 NC Not connection, this pin should be open26 NC Not connection, this pin should be open27 NC Not connection28 VDD1 Power Supply:+5V29 VDD230 VDD3uGXஔ {GGGGGGnuk

/ 55
