Haier LCD19W-M3 User Manual

To turn on the Haier LCD19W-M3 TV, follow the instructions provided in the 'Basic Operating Instructions' section on page 11 of the user manual. This section includes steps to power on the TV.

To select different input sources on the Haier LCD19W-M3 TV, refer to the 'Input selection' instructions provided in the 'Basic Operating Instructions' section on page 11 of the user manual. This section will guide you through the process of changing input sources.

To adjust the volume, use the VOL- (Volume Down) and VOL+ (Volume Up) buttons on the front panel. Pressing VOL- will decrease the volume, while pressing VOL+ will increase it. Additionally, these buttons can be used to navigate left and right in the on-screen display (OSD) menu.

To open or close the DVD tray, press the 'OPEN/CLOSE' button on the remote control.

To connect your PC to the Haier LCD19W-M3 using a VGA cable, follow these steps: 1. Ensure your PC has a VGA connector. 2. Turn off both the LCD-TV and the PC. 3. Connect a VGA cable to the VGA video interface connector on the PC and the other end to the VGA IN connector on the back of the LCD-TV. Tighten the screws on the VGA connectors. 4. Connect the audio cable to the audio input on the back of your LCD-TV. 5. Turn on the LCD-TV first, then turn on the PC. 6. Press the SOURCE button to set the video input mode of the LCD-TV to PC. 7. Adjust the resolution, refresh rate, brightness, and contrast on the menu until the picture is clear.

To connect a DVD player to the Haier LCD19W-M3 TV using the SCART input, follow these steps: 1. Connect the SCART lead from the DVD player to the TV's SCART socket. 2. Press the SOURCE button on the remote control to select SCART mode. 3. Press the Play button on the DVD player, and the content should appear on the screen.

You can use the number keys on the remote control to directly select TV channels. For channels 0 to 9, press the -/-- button until - is indicated on the screen and then press the relevant key. For channels bigger than 9, press the -/-- button until -- is indicated and then enter the two digits of the channel number. If you want to choose a one-digit channel in this condition, press 0 first and then the one-digit number key.

To use the Program Swap function, press the SWAP(Q.VIEW) button. If you are currently on channel 18 and want to return to the last watched channel 8, press the SWAP(Q.VIEW) button. Press it again to return to channel 18. This function allows you to easily switch between the last two watched channels.

To adjust the picture quality, press the MENU button and navigate to the Picture Menu. Use the V+/V- buttons to adjust settings like VIDEO MODE, CONTRAST, BRIGHTNESS, COLOUR, SHARPNESS, NOISE REDUCE, and COLOUR TEMP. Repeat the adjustments until you achieve your desired picture quality.

To adjust the sound settings, press the MENU button and use the V+/V- buttons to navigate to the AUDIO menu. From there, you can adjust settings like AUDIO MODE, BASS, TREBLE, BALANCE, and AVL to your preference.
