Haier L2627 Owner's Manual

To connect a DVD player using component cables, use the COMPONENT IN jacks labeled Y, Pb, and Pr on the back panel of the TV. Connect the corresponding component cables from your DVD player to these jacks.

Yes, you can connect your PC to the TV using the PC IN or PC/DVI jacks on the back panel. For audio, use the PC/DVI Audio Input. This allows you to use the TV as a monitor for your PC.

For better TV reception, it is recommended to use a CATV system or an outdoor antenna. The quality of over-the-air TV reception will depend on your antenna type, antenna location, and antenna positioning.

To switch to an external input source, use the INPUT button on the remote control to select the desired source. Press the / button to navigate through the available sources, press the OK button to confirm your selection, and then operate the corresponding external equipment.

To adjust the contrast and brightness, press the MENU button on the remote control, then use the / button to select the Video menu. Use the or OK button to select Contrast or Brightness, and then use the / button to adjust the settings to your preference. Contrast adjusts the intensity of bright parts, while Brightness adjusts the light output of the entire picture, mainly affecting the darker areas.

To switch between Mono, Stereo, and SAP modes, press the SAP button on the remote control. Each press will cycle through the available modes. If the broadcast is in Mono, the TV will automatically receive it in Mono mode, even if Stereo or SAP is selected. For digital signals with other languages, use the SAP button to select the desired language.

To set the date and time, press the MENU button on the remote control, then use the / button to select the Time menu. Press the or OK button and use the / button to select Date/Time. Choose between Manual or Auto mode for setting the date and time. Once you have made your selection, press the MENU button to return to the previous menu or the EXIT button to return to TV viewing.

To set the timer to turn on the TV at a specific time, follow these steps: 1. Press the MENU button and then use the / button to select the Time menu. 2. Press the or OK button and then use the / button to select the Timer. 3. Press the or OK button and then use the / button to select the On Mode. 4. Press the OK button to confirm. Then press the / button to move the cursor and the / button to set the desired time. 5. When you are satisfied with your choice, press the MENU button to return to the previous menu or press the EXIT button to return to TV viewing.

To change the language of the menu and indications, follow these steps: 1. Press the MENU button and then use the / button to select the Function menu. 2. Press the or OK button and then use the / button to select Menu Language. 3. Press the or OK button to select your preferred language (English, Spanish, or French). 4. When you are satisfied with your choice, press the EXIT button to return to normal viewing or press the MENU button to return to the previous menu.

If your Haier L2627 TV is not responding to the remote control, ensure that you have entered the correct code for your remote control brand from the 'Remote Control Codes' section. If the issue persists, try resetting the remote control by removing the batteries and reinserting them, then re-enter the code. If the problem continues, consult the troubleshooting section of the manual or contact customer support.
