Haier HL32XSL2a Owner's Manual

The model and serial number are located on a label at the back of the unit. Make sure to record these numbers for future reference and warranty service.

To access the on-screen menu, press the MENU button on the side panel of the TV.

To change the input source, press the INPUT button on the side panel repeatedly until you select the desired source.

To turn on and off the TV, press the POWER button on the remote control.

To adjust the volume, press the VOLUME UP or VOLUME DOWN buttons on the remote control.

To connect your PC to the Haier HL32XSL2a TV using VGA, follow these steps: 1. Connect the VGA cable from your PC to the VGA IN port on the TV. 2. If your graphic card outputs analog and digital RGB simultaneously, set the TV to VGA mode; the other mode will be set to Plug and Play automatically by the TV. 3. Make the corresponding audio connection. If using a sound card, adjust the VGA sound as required. 4. Turn on the computer and the TV. 5. Use the INPUT button on the remote control to select VGA source. 6. Check the image on your TV and adjust the resolution, refresh rate, brightness, and contrast as needed to get a clear picture.

If there is noise in the VGA mode on your Haier HL32XSL2a TV, try the following steps: 1. Change the VGA mode to another resolution. 2. Change the refresh rate to another rate. 3. Adjust the brightness and contrast on the menu until the picture is clear. If the refresh rate of the VGA graphic card cannot be changed, consider changing the VGA graphic card or consulting the manufacturer of the VGA graphic card.

The Parental Control function can be used to block specific channels, ratings, and other viewing sources. You can block program viewing based on the ratings sent by the broadcasting station. The default setting allows all programs to be viewed. To block viewing, choose the type of program and the categories you want to restrict.

To enable closed captions, you can use the CCD function in ATV mode. You can configure the captions to display in various formats such as Off, CC 1, CC 2, CC 3, CC 4, Text 1, Text 2, Text 3, or Text 4.

The production of the LED screen requires high and precision technologies. However, some dark or bright (red, blue, or green) spots, or some anomalous stripes or spots, might appear. This is not considered a defect and is a normal characteristic of the screen.
