Haier HL22XSLW2 Service Manual

The instructions for setting up the remote control are provided in section 6-3 of the manual.

The Haier HL22XSLW2 supports a maximum resolution of 1920x1080.

The Haier HL22XSLW2 has 181 preset channels.

To set up the A/V source on the Haier HL22XSLW2 TV, first connect the audio and video cables from the external equipment’s output jacks to the TV input jacks. Then, use the INPUT button on the remote control to select the proper input source. Press the / button to select the source, and then press the ENTER button to confirm.

To connect headphones to the Haier HL22XSLW2, plug a set of headphones into the 3.5mm mini-jack socket located on the rear panel of the set. Note that when headphones are connected, you will not receive sound from the speakers.

If the polarized AC cord does not fit into a non-polarized AC outlet, do not attempt to file or cut the blade. It is recommended to have an electrician replace the obsolete outlet with a polarized one.

The Auto Color function can be used in the VGA and Component models. If you notice abnormal color display, you can use this function to adjust the color automatically.

The backlight adjustment feature on the Haier HL22XSLW2 allows you to adjust the brightness of the display to suit your viewing preferences.

Verify if the sound system is set correctly. Refer to the relevant chapter in the manual for adjustments.

A horizontal gray line on the screen indicates a TCP failure, which could be due to something electric entering the LCD, awful environment, ACF bonding short, or TCP lead cracking.
