Haier 42D3500 Service Manual

Contents

Table of Contents2

Chapter 1. General Information4

Chapter 2. SpeciCation9

Chapter 3. Disassemble and Assemble12

Chapter 4. Location of Controls and Components14

Chapter 5. Installation Instructions19

Chapter 6. Operation Instructions21

Chapter 7. Electrical Parts24

Chapter 8. Measurements and Adjustments32

Chapter 9. Trouble Shooting36

Haier 42D3500 Service Manual Manual pdf 21 page image

1 POWER Press to turn the TV on and off.2 CH- TV channel down.3 CH+ TV channel up.4 VOL- Press to decrease the volume.5 VOL+ Press to increase the volume.6 MENU Press to select the main menu.7 INPUT Toggles between all the vailableinput sources.Service ManualModel No.: 42D3500Chapter 6. Operation Instructions6-1. Front Panel Controls20
